Φ2.2X7.5m ball mill equipment purchase notice
Ф2.2X7.5m ball mill equipment is one of the commonly used ball mill equipment. Through continuous technical transformation of Tongjia Industry, the ball mill equipment has been successfully upgraded to a bearing energy-saving ball mill equipment. Therefore, when purchasing a Ф2.2X7.5m ball mill equipment, Be sure to understand the parameters of the device so that you can better understand the price and performance of the device.
Ф2.2X7.5m ball mill equipment list and specifications:
I. Equipment list: ball mill equipment main body, motor, reducer, large ring gear, pinion, mill coupling, grinding head, screw feeding device, stern plate, liner and so on.
2.Equipment parameters:
(1) Ball mill specifications: Φ2.2 × 7.5m.
(2) Model: TJ2275
(3) Feeding strength: ≤25mm
(4) Production capacity: 15.6--18.1 tons/hour
(5) Effective volume: 24.8m3
(6) Grinding body speed: 20.4 (r/min)
(7) Motor model: JRQ1410-8-280, power: 380kW, voltage: 380V
(8) Reducer: ZD70 I = 5
(9) Maximum load of grinding body: 35 tons
(10) Equipment weight: 68 tons (excluding grinding body)
(11) Ball loading weight: 39.5 tons
Of course, the specific situation requires specific analysis. If you want to know more detailed ball mill equipment quotation, you can contact us Tongjia Industry.
