How to assemble the cylinder and end cover of the ceramic ball mill
When transporting, lay the end cap flat with the trunnion facing up so that the anti-rust paint on the trunnion can be washed off first. Due to the complex shape of the end cap, its center of gravity is difficult to find by calculation. Therefore, the two rope buckles, the main rope buckle and the main rope buckle, have no fixed place, so special lifting eyes must be made.
When making lifting lugs, consider having sufficient rigidity and strength. Dimensions A and B should be consistent with the bolt holes of the end cover bushing. The end cap lifting lugs should be placed near the end cap flange so that the main rope buckle can bear most of the lifting weight. A 5t chain block should be hung on the auxiliary rope buckle to adjust the straightness of the end cap. The position of the auxiliary cord buckle can be tied to the flange at the end of the end cap trunnion. After lifting the end cover straight, use sleepers to support it on the workshop floor. Thoroughly clean the flange and joint surface, wash off the oil stain and anti-rust coating, file off the local raised marks with a fine file, and check the flatness of the flange joint with a steel ruler. This work should be done with extreme care and must be carried out carefully.
